Inconel 625 Sheet Plate

Inconel 625 Circles, Inconel 625 Export Quality Sheet & Plate Stockists in India, Inconel Alloy 625 Hot Rolled (HR) Sheet & Plates, Inconel 625 Sheet and Plate Supplier in India, ASME SB 168 Inconel 625 Sheet, Inconel Alloy 625 Shim Sheets, Inconel 625 Cold Rolled (CR) Sheet & Plate, ASTM B168 Inconel 625 Sheet & Plate Exporter, Inconel 625 Plates Stockists in Mumbai, Inconel 625 Perforated Sheets Supplier in Mumbai, Inconel 625 Coils.

Table of Content

• What is Inconel 625 Plates
• Specification of Inconel 625 Plates
• Equivalent Grade of Inconel 625 Plates
• Chemical Composition of Inconel 625 Plates
• Applications and Uses of Inconel 625 Plates
• Packaging of Inconel 625 Plates
• Testing of Inconel 625 Plates
• People also Search For Inconel 625 Plates
• Export Destinations
• Domestic Supply

Silicon Steels is one of the best manufacturers, suppliers, stockiest, and exporter of Inconel 625 Sheets / Plates. At silicon steel, these Inconel UNS N06625 Sheets / Plates are manufactured following international industrial norms and using top quality raw material and latest technology. Inconel ASTM B168 UNS N06625 Sheets / Plates are available in different shapes and sizes. However customers can also order these sheets as per their customize specifications. Its thickness ranges from 0.1 mm to 30 mm. Inconel 625 sheets possesses high tensile strength and yield strength.

Inconel 625 Coils are non – magnetic. Inconel 625 Sheets contains chromium content up to 23%, ferrite content up to 5%, and nickel content up to 58%. Inconel UNS N06625 Seamless Slitting Coil provides an outstanding corrosion resistance to oxidation corrosion. It also has the best corrosion resistance to seawater corrosion. These Inconel 625 Sheets provides the best corrosion resistance at high elevated temperature. Inconel 625 Sheets also contains 0.50% manganese and silicon content. It has excellent corrosion resistance to pitting and crevice corrosion. Inconel 625 Plates possesses high yield strength and toughness. It also possesses good mechanical and welding properties. Inconel 625 Sheets provides an excellent corrosion resistance to stress corrosion cracking.

Inconel Alloy 625 Sheets, Inconel 625 HR Sheets, Nickel Alloy 625 #8 Finish Plates, Alloy 625 Sheets & Plates, ASTM B168 625 Inconel Sheets, Inconel Grade 625 Sheets Supplier in Mumbai, 2B Finish Inconel Alloy 625 Sheets, Inconel 625 Plates, Inconel Grade 625 Sheets / Plates at Best Price, DIN 2.4856 Plates, Gr 625 Inconel Cold Rolled Plates, Nickel Alloy 625 Sheets, Inconel UNS N06625 Sheets, ASME SB 168 Alloy 625 Plates, Inconel Alloy 625 Industrial Sheets and Plates Exporter in India, Inconel 625 Sheets and Plates Stockist, Inconel Alloy 625 Hot Rolled Plates, 625 Inconel CR Sheets.

Inconel 625 Sheets are mostly used in food processing equipment and food packaging equipment. It is also used in marine industry and seawater equipment. Inconel 625 Plates are often used in the pulp and paper industry and offshore oil drilling companies. Inconel 625 coils can be used extensively in chemical equipment, pharmaceutical equipment, and gas processing units. It is also used widely in aircraft and aerospace industry.

Specification :

Specifications	ASTM B168 / ASME SB168
Thickness	4mm-100mm
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface	2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hairline, sand blast, Brush, etching, etc
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)

Types of Inconel 625 Sheet/ Plate :

	ASTM B443 Inconel 625 Hot rolled Sheet ASME SB443 UNS N06625 Cold Rolled Sheet Werkstoff Nr. 2.4856 2B Finish Sheet	Afnor Nc22Dnb4M 2D Finish Sheet EN Nicr22Mo9Nb Ba Finish Sheet JIS Ncf 625 Satin Finish Sheet	BS Na 21 No.4 Sheet Gost Хн75Мбтю Hot rolled Sheet
	ASTM B443 Inconel 625 Hot rolled Plate ASME SB443 UNS N06625 Cold Rolled Plate Werkstoff Nr. 2.4856 2B Finish Plate	Afnor Nc22Dnb4M 2D Finish Plate EN Nicr22Mo9Nb Ba Finish Plate JIS Ncf 625 Satin Finish Plate	BS Na 21 No.4 Plate Gost Хн75Мбтю Hot rolled Plate
	ASTM B443 Inconel 625 Hot rolled Coils ASME SB443 UNS N06625 Cold Rolled Coils Werkstoff Nr. 2.4856 2B Finish Coils	Afnor Nc22Dnb4M 2D Finish Coils EN Nicr22Mo9Nb Ba Finish Coils JIS Ncf 625 Satin Finish Coils	BS Na 21 No.4 Coils Gost Хн75Мбтю Hot rolled Coils
	ASTM B443 Inconel 625 Hot rolled Foils ASME SB443 UNS N06625 Cold Rolled Foils Werkstoff Nr. 2.4856 2B Finish Foils	Afnor Nc22Dnb4M 2D Finish Foils EN Nicr22Mo9Nb Ba Finish Foils JIS Ncf 625 Satin Finish Foils	BS Na 21 No.4 Foils Gost Хн75Мбтю Hot rolled Foils
	ASTM B443 Inconel 625 Hot rolled Strip ASME SB443 UNS N06625 Cold Rolled Strip Werkstoff Nr. 2.4856 2B Finish Strip	Afnor Nc22Dnb4M 2D Finish Strip EN Nicr22Mo9Nb Ba Finish Strip JIS Ncf 625 Satin Finish Strip	BS Na 21 No.4 Strip Gost Хн75Мбтю Hot rolled Strip
	ASTM B443 Inconel 625 Hot rolled Shim Sheet ASME SB443 UNS N06625 Cold Rolled Shim Sheet Werkstoff Nr. 2.4856 2B Finish Shim Sheet	Afnor Nc22Dnb4M 2D Finish Shim Sheet EN Nicr22Mo9Nb Ba Finish Shim Sheet JIS Ncf 625 Satin Finish Shim Sheet	BS Na 21 No.4 Shim Sheet Gost Хн75Мбтю Hot rolled Shim Sheet
	ASTM B443 Inconel 625 Hot rolled Roll ASME SB443 UNS N06625 Cold Rolled Roll Werkstoff Nr. 2.4856 2B Finish Roll	Afnor Nc22Dnb4M 2D Finish Roll EN Nicr22Mo9Nb Ba Finish Roll JIS Ncf 625 Satin Finish Roll	BS Na 21 No.4 Roll Gost Хн75Мбтю Hot rolled Roll
	ASTM B443 Inconel 625 Hot rolled Perforated Sheet ASME SB443 UNS N06625 Cold Rolled Perforated Sheet Werkstoff Nr. 2.4856 2B Finish Perforated Sheet	Afnor Nc22Dnb4M 2D Finish Perforated Sheet EN Nicr22Mo9Nb Ba Finish Perforated Sheet JIS Ncf 625 Satin Finish Perforated Sheet	BS Na 21 No.4 Perforated Sheet Gost Хн75Мбтю Hot rolled Perforated Sheet
	ASTM B443 Inconel 625 Hot rolled Chequered Plate ASME SB443 UNS N06625 Cold Rolled Chequered Plate Werkstoff Nr. 2.4856 2B Finish Chequered Plate	Afnor Nc22Dnb4M 2D Finish Chequered Plate EN Nicr22Mo9Nb Ba Finish Chequered Plate JIS Ncf 625 Satin Finish Chequered Plate	BS Na 21 No.4 Chequered Plate Gost Хн75Мбтю Hot rolled Chequered Plate
	ASTM B443 Inconel 625 Hot rolled Ring ASME SB443 UNS N06625 Cold Rolled Ring Werkstoff Nr. 2.4856 2B Finish Ring	Afnor Nc22Dnb4M 2D Finish Ring EN Nicr22Mo9Nb Ba Finish Ring JIS Ncf 625 Satin Finish Ring	BS Na 21 No.4 Ring Gost Хн75Мбтю Hot rolled Ring
	ASTM B443 Inconel 625 Hot rolled Circle ASME SB443 UNS N06625 Cold Rolled Circle Werkstoff Nr. 2.4856 2B Finish Circle	Afnor Nc22Dnb4M 2D Finish Circle EN Nicr22Mo9Nb Ba Finish Circle JIS Ncf 625 Satin Finish Circle	BS Na 21 No.4 Circle Gost Хн75Мбтю Hot rolled Circle
	ASTM B443 Inconel 625 Hot rolled Flats ASME SB443 UNS N06625 Cold Rolled Flats Werkstoff Nr. 2.4856 2B Finish Flats	Afnor Nc22Dnb4M 2D Finish Flats EN Nicr22Mo9Nb Ba Finish Flats JIS Ncf 625 Satin Finish Flats	BS Na 21 No.4 Flats Gost Хн75Мбтю Hot rolled Flats

Equivalent Grade :

Grade	UNS No	Old British		Euronorm		GOST	Japanese JIS
		BS	En	No	AFNOR
Inconel 625	N06625	NA 21	NiCr22Mo9Nb	2.4856	NC22DNB4M	ХН75МБТЮ	NCF 625

Chemical Composition :

Grade		C	Mn	Si	Fe	S	Cr2	Al-Ti	Ni
625	min.	–	–	–	–	–	20.0	–	58.0
	max.	0.10	0.50	0.50	5.0	0.015	23.0	0.40	–

Dimensions of Inconel 625 Plate

Inconel 625 Plate Metric Dimensions

Surface finish	Thickness (mm)	Width (mm)
2B – Cold rolled, heat treated, pickled, skin passed	0.25–8.0	max. 2032
2D – Cold rolled, heat treated, pickled	0.4–6.35	max. 1524
2E – Cold rolled, heat treated, mechanically descaled	0.4–8.0	max. 2032
2R – Cold rolled, bright annealed	0.25–3.5	max. 1524
2H – Work hardened	0.4–6.35	max. 1524
Polished, brushed	0.5–4.0	max. 1524

Imperial Dimensions of Inconel 625 Sheet

Surface finish	Gauge (in)	Width (in)
2B – Cold rolled, heat treated, pickled, skin passed	10–24	max. 72*
2D – Cold rolled, heat treated, pickled	12–24	max. 60
BA Mexinox only	18–28	max. 48
Polished (not brushed)	11–24	max. 60
Temper rolled Mexinox only	13–29	max. 48

Weight Chart of Inconel 625 Plate

Thickness	Plate Weight per Unit Area	Density
3/16 inches	0.06000 lbs/in²42.184176 kg/m²	0.315 lbs/in³8.72 g/cm³
1/4 inches	0.08 lbs/in²56.245568 kg/m²	0.315 lbs/in³8.72 g/cm³
3/8 inches	0.121 lbs/in²85.0714216 kg/m²	0.315 lbs/in³8.72 g/cm³
1/2 inches	0.161 lbs/in²113.1942056 kg/m²	0.315 lbs/in³8.72 g/cm³
5/8 inches	0.196 lbs/in²137.8016416 kg/m²	0.315 lbs/in³8.72 g/cm³
3/4 inches	0.235 lbs/in²165.221356 kg/m²	0.315 lbs/in³8.72 g/cm³
7/8 inches	0.274 lbs/in²192.6410704 kg/m²	0.315 lbs/in³8.72 g/cm³
1 inches	0.313 lbs/in²220.0607848 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/4 inches	0.391 lbs/in²274.9002136 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/2 inches	0.47 lbs/in²330.442712 kg/m²	0.315 lbs/in³8.72 g/cm³
1 3/4 inches	0.549 lbs/in²385.9852104 kg/m²	0.315 lbs/in³8.72 g/cm³
2 inches	0.627 lbs/in²440.8246392 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/4 inches	0.705 lbs/in²495.664068 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/2 inches	0.784 lbs/in²551.2065664 kg/m²	0.315 lbs/in³8.72 g/cm³
2 3/4 inches	0.862 lbs/in²606.0459952 kg/m²	0.315 lbs/in³8.72 g/cm³
3 inches	0.941 lbs/in²661.5884936 kg/m²	0.315 lbs/in³8.72 g/cm³

Prices of Inconel 625 Plate / Sheet :

ASTM B168 Type Inconel 625 Plate
FOB Price: 1 X 1 MTR X 40 mm Thk : US $ 3120

1.5mm Inconel 625 Plate
FOB Price: 200 MM X 60 X 3 MM : US $ 73

ASTM B168 Gr Inconel 625 Plate Material
FOB Price: 4mm X 1500m X 3000m : US $ 930

SB168 GR Inconel 625 Clad Plate
FOB Price: 2 MTR X 2 MTR X6 MM THK : US $ 2966

Inconel 625 Sheet
FOB Price: 730 X 2080 X 8.5 mm : US $ 877

Polished SB168 TP Inconel 625 Sheet
FOB Price: 150X25X6.00 MM : US $ 82

2B Finish Duplex Alloy Inconel 625 Sheet
FOB Price: 6mm X 0.625m X 0.8000 m : US $ 252

Avesta Inconel 625 Perforated Sheet
FOB Price: 3.00 X 1500 X3000 : US $ 4.91/Kg

SB168 Inconel 625 Trim Plate
FOB Price: 1M X 5M X6 mm THK: US $ 5168

2mm thick Inconel 625 Steel Plate
FOB Price: 2 MTR X 2 MTR X2 MM THK : US $ 2356

SB168 Type Inconel 625 Shims Plate
FOB Price: 1 m X 1 m X 4mm THK: US $ 876

10mm thick Inconel 625 Alloy Plate
FOB Price: 10 mm THK X 4 FT X 8 FT : US $ 2898

Hot rolled Inconel 625 Plate
FOB Price: 1500 X 3415 2 MM : US $ 1214

Inconel 625 Coil
FOB Price: 10.00 X 200 X300 : US $ 4.93/Kg

ASTM B168 Type Inconel 625 Strip
FOB Price: 80 X 0.2 MM THK : US $ 15.51/Kg

Inconel 625 Foil
FOB Price: .024 HEIGHT X 0.75 WIDE X 50M : US $ 789

Applications :

These material are not a single material but the name for a family of corrosion resistant steels. Like many scientific breakthrough the origins of stainless steel lies in a lucky accident. From the smallest part of zipper to the largest building skyscraper, stainless steel is an essential part of modern life.Stainless steel’s strength, resistance to corrosion and low maintenance make it the ideal material for a wide range of applications. It is also has a long life cycle and is 100% recyclable.

Packaging Used By Us :

We ship our stainless steel metal products in industry leading packaging designed to ensure your order reaches its destination safely. We offer multiple packaging options to meet your specific requirements. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging. We pack our goods in numerous ways based on the products. We pack our products in multiple ways.

Testing Used By Us :

To specify the various physical and mechanical properties of the finished product, various tests, both destructive and nondestructive, are performed. Metallurgical, hardness, hardenability, tension, ductility, compression, fatigue, impact, wear, corrosion, creep, machinability, radiography, magnetic particle, ultrasonic, and eddy current are some of the major tests that are performed by quality control personnel. Metallurgical testing is used to determine the quality of steel by analyzing the microstructure of a sample under a microscope. A cross section of a sample is first highly polished and then examined at a magnification from 100-500 diameters. The microstructure of steel consists of grains of different compositions and sizes.
