Stainless Steel 316TI Sheet plate

DIN 1.4571 Stainless Steel 316Ti Galvanized Plates Dealer, Stainless Steel 316Ti Plates, 316Ti Stainless Steel Sheets, SS 316Ti Coils, Stainless Steel Workstoff NR. 1.4571 Plates, Stainless Steel 316Ti Hot Rolled Sheets & Plates, SS 316Ti Chequered Plates Stockists & Exporters, Stainless Steel UNS S31635 Perforated Sheets, Plates & Coils, SS 316Ti Sheets, ASTM A240 Stainless Steel 316Ti Sheets, Stainless Steel 316Ti Decorative Sheets Supplier, Stainless Steel Sheets & Plates, 316Ti SS Polished Sheets & Plates, Stainless Steel 316Ti Coils.

Table of Content

• What is Stainless Steel 316Ti Plates
• Specification of Stainless Steel 316Ti Plates
• Equivalent Grade of Stainless Steel 316Ti Plates
• Chemical Composition of Stainless Steel 316Ti Plates
• Applications and Uses of Stainless Steel 316Ti Plates
• Packaging of Stainless Steel 316Ti Plates
• Testing of Stainless Steel 316Ti Plates
• People also Search For Stainless Steel 316Ti Plates
• Export Destinations
• Domestic Supply

Silicon Steels is known to be the best manufacturer, supplier, stockiest, and exporter of stainless steel 316Ti Sheet / Plate, which are produced using the best quality raw material and under the direction of highly experienced and skilled experts. Stainless Steel 316Ti Sheet provides the best corrosion resistance to pitting and crevice corrosion. We always manufacture stainless steel 316Ti Sheet / Plate following international norms and standards. These Stainless steel 316Ti Sheets / Plates are highly durable and are very easy to install and maintain. It comes at a very affordable price.

Stainless Steel 316Ti Sheet’s chemical composition is as follows: It contains chromium content up to 18%, Nickel content up to 14%, 3% molybdenum content, and 2% & 0.75% manganese and silicon content respectively. These Stainless Steel 316Ti Plates are highly resistant to heat corrosion and many corrosive media. It also possesses high welding properties. These Stainless Steel 316Ti Sheets have the best corrosion resistance to stress corrosion cracking and are magnetic. Stainless Steel 316Ti Sheet is an austenitic Chromium-Nickel – Molybdenum grade. It offers better corrosion resistance to oxidation corrosion. Once the Stainless Steel 316Ti Sheet / Plate gets manufactured, it passes through several tests such as material tests, corrosion resistance tests, etc.

ASTM A240 SS 316TI Plates, ASME A240 Stainless Steel 316Ti Plates, TP316TI SS Cold Rolled Coils, SS 316TI Industrial Sheets, Stainless Steel 1.4571 Sheets, Stainless Steel 316Ti Colled Rolled Sheets & Plates Dealer & Wholesaler, 316Ti SS Sheet Cut to Size, SUS 316TI Sheets, Stainless Steel 316TI Sheets, UNS S31635 Plate, Stainless Steel 316TI Coils, Plates and Coils Supplier in Mumbai, TP316TI SS Coils, 316TI Stainless Steel HR Sheets and Plate Manufacturer, Stainless Steel 316Ti Sheet Metal.

Stainless Steel 316Ti Sheets are mostly used in chemical processing equipment and pharmaceutical equipment. It is also used in the textile industry. Stainless steel 316Ti Plates are very often used In the pulp and paper industry. It can be extensively used in the oil & gas refinery, petroleum industry, and offshore oil drilling companies. It is also used in the aircraft and aerospace industry.

Specification :

Specifications	ASTM A240 / ASME SA240
Thickness	4mm-100mm
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface	2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hairline, sand blast, Brush, etching, etc
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)

Types of Stainless Steel 316TI Sheet/ Plate :

	ASTM A240 Stainless Steel 316Ti Hot rolled Sheet S31635 Stainless Steel Cold Rolled Sheet ASME A240 SS 316Ti 2B Finish Sheet	UNS S31635 2D Finish Sheet BS 320S31 Ba Finish Sheet EN X6Crnimoti17-12-2 Satin Finish Sheet 1.4571 No.4 Sheet	Afnor Z6Cndt17‐12 No.8 Sheet Gost 08Ch17N13M2T Matt Finish Sheet JIS SUS 316Ti Hot rolled Sheet
	ASTM A240 Stainless Steel 316Ti Hot rolled Plate S31635 Stainless Steel Cold Rolled Plate ASME A240 SS 316Ti 2B Finish Plate	UNS S31635 2D Finish Plate BS 320S31 Ba Finish Plate EN X6Crnimoti17-12-2 Satin Finish Plate 1.4571 No.4 Plate	Afnor Z6Cndt17‐12 No.8 Plate Gost 08Ch17N13M2T Matt Finish Plate JIS SUS 316Ti Hot rolled Plate
	ASTM A240 Stainless Steel 316Ti Hot rolled Coils S31635 Stainless Steel Cold Rolled Coils ASME A240 SS 316Ti 2B Finish Coils	UNS S31635 2D Finish Coils BS 320S31 Ba Finish Coils EN X6Crnimoti17-12-2 Satin Finish Coils 1.4571 No.4 Coils	Afnor Z6Cndt17‐12 No.8 Coils Gost 08Ch17N13M2T Matt Finish Coils JIS SUS 316Ti Hot rolled Coils
	ASTM A240 Stainless Steel 316Ti Hot rolled Foils S31635 Stainless Steel Cold Rolled Foils ASME A240 SS 316Ti 2B Finish Foils	UNS S31635 2D Finish Foils BS 320S31 Ba Finish Foils EN X6Crnimoti17-12-2 Satin Finish Foils 1.4571 No.4 Foils	Afnor Z6Cndt17‐12 No.8 Foils Gost 08Ch17N13M2T Matt Finish Foils JIS SUS 316Ti Hot rolled Foils
	ASTM A240 Stainless Steel 316Ti Hot rolled Strip S31635 Stainless Steel Cold Rolled Strip ASME A240 SS 316Ti 2B Finish Strip	UNS S31635 2D Finish Strip BS 320S31 Ba Finish Strip EN X6Crnimoti17-12-2 Satin Finish Strip 1.4571 No.4 Strip	Afnor Z6Cndt17‐12 No.8 Strip Gost 08Ch17N13M2T Matt Finish Strip JIS SUS 316Ti Hot rolled Strip
	ASTM A240 Stainless Steel 316Ti Hot rolled Shim Sheet S31635 Stainless Steel Cold Rolled Shim Sheet ASME A240 SS 316Ti 2B Finish Shim Sheet	UNS S31635 2D Finish Shim Sheet BS 320S31 Ba Finish Shim Sheet EN X6Crnimoti17-12-2 Satin Finish Shim Sheet 1.4571 No.4 Shim Sheet	Afnor Z6Cndt17‐12 No.8 Shim Sheet Gost 08Ch17N13M2T Matt Finish Shim Sheet JIS SUS 316Ti Hot rolled Shim Sheet
	ASTM A240 Stainless Steel 316Ti Hot rolled Rolls S31635 Stainless Steel Cold Rolled Rolls ASME A240 SS 316Ti 2B Finish Rolls	UNS S31635 2D Finish Rolls BS 320S31 Ba Finish Rolls EN X6Crnimoti17-12-2 Satin Finish Rolls 1.4571 No.4 Rolls	Afnor Z6Cndt17‐12 No.8 Rolls Gost 08Ch17N13M2T Matt Finish Rolls JIS SUS 316Ti Hot rolled Rolls
	ASTM A240 Stainless Steel 316Ti Hot rolled Perforated Sheet S31635 Stainless Steel Cold Rolled Perforated Sheet ASME A240 SS 316Ti 2B Finish Perforated Sheet	UNS S31635 2D Finish Perforated Sheet BS 320S31 Ba Finish Perforated Sheet EN X6Crnimoti17-12-2 Satin Finish Perforated Sheet 1.4571 No.4 Perforated Sheet	Afnor Z6Cndt17‐12 No.8 Perforated Sheet Gost 08Ch17N13M2T Matt Finish Perforated Sheet JIS SUS 316Ti Hot rolled Perforated Sheet
	ASTM A240 Stainless Steel 316Ti Hot rolled Chequered Plate S31635 Stainless Steel Cold Rolled Chequered Plate ASME A240 SS 316Ti 2B Finish Chequered Plate	UNS S31635 2D Finish Chequered Plate BS 320S31 Ba Finish Chequered Plate EN X6Crnimoti17-12-2 Satin Finish Chequered Plate 1.4571 No.4 Chequered Plate	Afnor Z6Cndt17‐12 No.8 Chequered Plate Gost 08Ch17N13M2T Matt Finish Chequered Plate JIS SUS 316Ti Hot rolled Chequered Plate
	ASTM A240 Stainless Steel 316Ti Hot rolled Ring S31635 Stainless Steel Cold Rolled Ring ASME A240 SS 316Ti 2B Finish Ring	UNS S31635 2D Finish Ring BS 320S31 Ba Finish Ring EN X6Crnimoti17-12-2 Satin Finish Ring 1.4571 No.4 Ring	Afnor Z6Cndt17‐12 No.8 Ring Gost 08Ch17N13M2T Matt Finish Ring JIS SUS 316Ti Hot rolled Ring
	ASTM A240 Stainless Steel 316Ti Hot rolled Circle S31635 Stainless Steel Cold Rolled Circle ASME A240 SS 316Ti 2B Finish Circle	UNS S31635 2D Finish Circle BS 320S31 Ba Finish Circle EN X6Crnimoti17-12-2 Satin Finish Circle 1.4571 No.4 Circle	Afnor Z6Cndt17‐12 No.8 Circle Gost 08Ch17N13M2T Matt Finish Circle JIS SUS 316Ti Hot rolled Circle
	ASTM A240 Stainless Steel 316Ti Hot rolled Flats S31635 Stainless Steel Cold Rolled Flats ASME A240 SS 316Ti 2B Finish Flats	UNS S31635 2D Finish Flats BS 320S31 Ba Finish Flats EN X6Crnimoti17-12-2 Satin Finish Flats 1.4571 No.4 Flats	Afnor Z6Cndt17‐12 No.8 Flats Gost 08Ch17N13M2T Matt Finish Flats JIS SUS 316Ti Hot rolled Flats

Equivalent Grade :

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 316TI	1.4571	S31635	SUS 316Ti	320S31	08Ch17N13M2T	Z6CNDT17‐123	X6CrNiMoTi17-12-2

Chemical Composition :

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
316TI	min.	–	–	–	–	–	16.0	2.0-3.0	10.0	–
	max.	0.08	2.0	0.75	0.045	0.030	18.0		14.0	0.1

Dimensions of Stainless Steel 316TI Plate

Stainless Steel 316TI Plate Metric Dimensions

Surface finish	Thickness (mm)	Width (mm)
2B – Cold rolled, heat treated, pickled, skin passed	0.25–8.0	max. 2032
2D – Cold rolled, heat treated, pickled	0.4–6.35	max. 1524
2E – Cold rolled, heat treated, mechanically descaled	0.4–8.0	max. 2032
2R – Cold rolled, bright annealed	0.25–3.5	max. 1524
2H – Work hardened	0.4–6.35	max. 1524
Polished, brushed	0.5–4.0	max. 1524

Imperial Dimensions of Stainless Steel 316TI Sheet

Surface finish	Gauge (in)	Width (in)
2B – Cold rolled, heat treated, pickled, skin passed	10–24	max. 72*
2D – Cold rolled, heat treated, pickled	12–24	max. 60
BA Mexinox only	18–28	max. 48
Polished (not brushed)	11–24	max. 60
Temper rolled Mexinox only	13–29	max. 48

Weight Chart of Stainless Steel 316TI Plate

Thickness	Plate Weight per Unit Area	Density
3/16 inches	0.06000 lbs/in²42.184176 kg/m²	0.315 lbs/in³8.72 g/cm³
1/4 inches	0.08 lbs/in²56.245568 kg/m²	0.315 lbs/in³8.72 g/cm³
3/8 inches	0.121 lbs/in²85.0714216 kg/m²	0.315 lbs/in³8.72 g/cm³
1/2 inches	0.161 lbs/in²113.1942056 kg/m²	0.315 lbs/in³8.72 g/cm³
5/8 inches	0.196 lbs/in²137.8016416 kg/m²	0.315 lbs/in³8.72 g/cm³
3/4 inches	0.235 lbs/in²165.221356 kg/m²	0.315 lbs/in³8.72 g/cm³
7/8 inches	0.274 lbs/in²192.6410704 kg/m²	0.315 lbs/in³8.72 g/cm³
1 inches	0.313 lbs/in²220.0607848 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/4 inches	0.391 lbs/in²274.9002136 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/2 inches	0.47 lbs/in²330.442712 kg/m²	0.315 lbs/in³8.72 g/cm³
1 3/4 inches	0.549 lbs/in²385.9852104 kg/m²	0.315 lbs/in³8.72 g/cm³
2 inches	0.627 lbs/in²440.8246392 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/4 inches	0.705 lbs/in²495.664068 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/2 inches	0.784 lbs/in²551.2065664 kg/m²	0.315 lbs/in³8.72 g/cm³
2 3/4 inches	0.862 lbs/in²606.0459952 kg/m²	0.315 lbs/in³8.72 g/cm³
3 inches	0.941 lbs/in²661.5884936 kg/m²	0.315 lbs/in³8.72 g/cm³

Prices of Stainless Steel 316TI Plate / Sheet :

ASTM A240 Type SS 316TI Plate
FOB Price: 1 X 1 MTR X 40 mm Thk : US $ 3120

1.5mm SS 316TI Plate
FOB Price: 200 MM X 60 X 3 MM : US $ 73

ASTM A240 Gr SS 316TI Plate Material
FOB Price: 4mm X 1500m X 3000m : US $ 930

SA 240 GR SS 316TI Clad Plate
FOB Price: 2 MTR X 2 MTR X6 MM THK : US $ 2966

SS 316TI Sheet
FOB Price: 730 X 2080 X 8.5 mm : US $ 877

Polished SA 240 TP SS 316TI Sheet
FOB Price: 150X25X6.00 MM : US $ 82

2B Finish Duplex Alloy SS 316TI Sheet
FOB Price: 6mm X 0.600m X 0.8000 m : US $ 252

Avesta SS 316TI Perforated Sheet
FOB Price: 3.00 X 1500 X3000 : US $ 4.91/Kg

SA-240 SS 316TI Trim Plate
FOB Price: 1M X 5M X6 mm THK: US $ 5168

2mm thick SS 316TI Steel Plate
FOB Price: 2 MTR X 2 MTR X2 MM THK : US $ 2356

SA 240 Type SS 316TI Shims Plate
FOB Price: 1 m X 1 m X 4mm THK: US $ 876

10mm thick SS 316TI Alloy Plate
FOB Price: 10 mm THK X 4 FT X 8 FT : US $ 2898

Hot rolled SS 316TI Plate
FOB Price: 1500 X 3415 2 MM : US $ 1214

SS 316TI Coil
FOB Price: 10.00 X 200 X300 : US $ 4.93/Kg

ASTM A240 Type SS 316TI Strip
FOB Price: 80 X 0.2 MM THK : US $ 15.51/Kg

SS 316TI Foil
FOB Price: .024 HEIGHT X 0.75 WIDE X 50M : US $ 789

Applications :

These material are not a single material but the name for a family of corrosion resistant steels. Like many scientific breakthrough the origins of stainless steel lies in a lucky accident. From the smallest part of zipper to the largest building skyscraper, stainless steel is an essential part of modern life.Stainless steel’s strength, resistance to corrosion and low maintenance make it the ideal material for a wide range of applications. It is also has a long life cycle and is 100% recyclable.

Packaging Used By Us :

We ship our stainless steel metal products in industry leading packaging designed to ensure your order reaches its destination safely. We offer multiple packaging options to meet your specific requirements. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging. We pack our goods in numerous ways based on the products. We pack our products in multiple ways.

Testing Used By Us :

To specify the various physical and mechanical properties of the finished product, various tests, both destructive and nondestructive, are performed. Metallurgical, hardness, hardenability, tension, ductility, compression, fatigue, impact, wear, corrosion, creep, machinability, radiography, magnetic particle, ultrasonic, and eddy current are some of the major tests that are performed by quality control personnel. Metallurgical testing is used to determine the quality of steel by analyzing the microstructure of a sample under a microscope. A cross section of a sample is first highly polished and then examined at a magnification from 100-500 diameters. The microstructure of steel consists of grains of different compositions and sizes.
